Mogami 2319 Standard Grade Insert Direct Out Cable, EHS-Built

Model/Part Number: MB-DIR-XX-M2319-LLL
Price: $26.80
Eligible For Free Shipping
(Orders Over $75)
This is our custom-built Insert as Direct out cable. It has a TRS (stereo or balanced) 1/4" connector on one end that plugs into a mixer's insert connection and is designed to pass signal out and directly to the signal return (the ring contact). This enables the insert to be used for a key input or a recorder or other device without the need to half patch or break the mixers channel path. The TRS (insert) end is labeled with "Insert Direct Out" (printed black on white shrink unless the color label is selected). You can select the connector you need for the other end.

Construction is Neutrik connectors with Mogami 2319 cable. Neutrik connectors are some of the best connectors around. Mogami 2319 cable is very flexible, durable, light-weight cable.
  • Our high-quality cable made-to-order
  • Custom Built: BETTER, FASTER, MORE OPTIONS
  • Insert Direct out cable
  • Lots of connector options
    • XLR
    • RCA
    • 1/4"
    • Many Many More
  • Great price
  • Mogami 2319 cable
  • Neutrik, Switchcraft and other high-quality connectors
  • Optional color label
  • Optional colored boot for 1/4" and XLR only (photo shows XLR Boot)
  • Option select the length you want
  • Optional custom label (standard label is black text on white shrink, change shrink color with the "Color Label" option)
    • Your name, company, or phone number
    • What it's connecting to or from, for example, "CD out" "Channel 1 In" etc.
    • Length label
    • Your logo, please contact before ordering
  • Length is the cut wire length and will be about mid-connector to mid-connector.
Photo 1 shows 4' cable with yellow shrink label and black and gold connectors and XLR male connector selected and close-up of the label.
Photo 2 shows two ends with yellow shrink label and black and gold and XLR male connector selected.
Photo 3 shows the wire thickness.
For more information about cable types, CLICK HERE.
For more information about cable lengths, CLICK HERE.
Available Options:
Click image to enlarge
Colored Boot:  -For XLR and 1/4" only
  Colored Boot
Click image to enlarge
Colored Boot: BlackBlack
Colored Boot: Blue (+$3.18)Blue (+$3.18)
Colored Boot: Brown (+$3.18)Brown (+$3.18)
Colored Boot: Gray (+$3.18)Gray (+$3.18)
Colored Boot: Green (+$3.18)Green (+$3.18)
Colored Boot: Orange (+$3.18)Orange (+$3.18)
Colored Boot: Red (+$3.18)Red (+$3.18)
Colored Boot: Violet (+$3.18)Violet (+$3.18)
Colored Boot: White (+$3.18)White (+$3.18)
Colored Boot: Yellow (+$3.18)Yellow (+$3.18)
  Colored Boot
Connector Insert End:  -Insert TRS Only
  Connector Insert End
Click image to enlarge
Connector  Insert End: - Please Select -- Please Select -
Connector  Insert End: TRS 1/4" (C series)TRS 1/4" (C series)
Connector  Insert End: TRS 1/4" (slim, PX series) (+$2.72)TRS 1/4" (slim, PX series) (+$2.72)
Connector  Insert End: TRS 1/4" Gold (slim, PX series) (+$6.12)TRS 1/4" Gold (slim, PX series) (+$6.12)
Connector  Insert End: TRS 1/4" Right Angle (PX series) (+$6.36)TRS 1/4" Right Angle (PX series) (+$6.36)
Connector  Insert End: TRS 1/4" Gold Right Angle (PX series) (+$10.98)TRS 1/4" Gold Right Angle (PX series) (+$10.98)
Connector A:  -Output
  Connector A
Click image to enlarge
Connector A: - Please Select -- Please Select -
Connector A: XLR Male (X series) (+$0.36)XLR Male (X series) (+$0.36)
Connector A: XLR Male (XX Series) (+$1.16)XLR Male (XX Series) (+$1.16)
Connector A: XLR Male Gold (X series) (+$1.95)XLR Male Gold (X series) (+$1.95)
Connector A: XLR Male Right Angle (RX series) (+$8.82)XLR Male Right Angle (RX series) (+$8.82)
Connector A: XLR Male Gold (XX Series) (+$12.57)XLR Male Gold (XX Series) (+$12.57)
Connector A: XLR Male Gold Right Angle (RX series) (+$12.57)XLR Male Gold Right Angle (RX series) (+$12.57)
Connector A: TS 1/4" (C series) (+$0.92)TS 1/4" (C series) (+$0.92)
Connector A: TS 1/4" Female (Rean) (+$1.72)TS 1/4" Female (Rean) (+$1.72)
Connector A: TS 1/4" (slim, PX series) (+$2.68)TS 1/4" (slim, PX series) (+$2.68)
Connector A: TS 1/4" Right Angle Flat (Hicon) (+$3.38)TS 1/4" Right Angle Flat (Hicon) (+$3.38)
Connector A: TS 1/4" Right Angle (PX series) (+$3.76)TS 1/4" Right Angle (PX series) (+$3.76)
Connector A: TS 1/4" Gold (slim, PX series) (+$4.39)TS 1/4" Gold (slim, PX series) (+$4.39)
Connector A: TS 1/4" Gold Right Angle (PX series) (+$4.98)TS 1/4" Gold Right Angle (PX series) (+$4.98)
Connector A: TS 1/4" Female (+$5.75)TS 1/4" Female (+$5.75)
Connector A: TS 1/4" Female Black (+$8.69)TS 1/4" Female Black (+$8.69)
Connector A: TRS 1/4" (C series) (+$1.27)TRS 1/4" (C series) (+$1.27)
Connector A: TRS 1/4" Female (Rean) (+$2.11)TRS 1/4" Female (Rean) (+$2.11)
Connector A: TRS 1/4" (slim, PX series) (+$3.99)TRS 1/4" (slim, PX series) (+$3.99)
Connector A: TRS 1/4" Right Angle Flat (Hicon) (+$4.59)TRS 1/4" Right Angle Flat (Hicon) (+$4.59)
Connector A: TRS 1/4" Female (+$5.75)TRS 1/4" Female (+$5.75)
Connector A: TRS 1/4" Gold (slim, PX series) (+$7.39)TRS 1/4" Gold (slim, PX series) (+$7.39)
Connector A: TRS 1/4" Right Angle (PX series) (+$7.63)TRS 1/4" Right Angle (PX series) (+$7.63)
Connector A: TRS 1/4" Female Black (+$8.69)TRS 1/4" Female Black (+$8.69)
Connector A: TRS 1/4" Gold Right Angle (PX series) (+$12.25)TRS 1/4" Gold Right Angle (PX series) (+$12.25)
Connector A: RCA BlackRCA Black
Connector A: RCA BlueRCA Blue
Connector A: RCA BrownRCA Brown
Connector A: RCA GrayRCA Gray
Connector A: RCA GreenRCA Green
Connector A: RCA OrangeRCA Orange
Connector A: RCA RedRCA Red
Connector A: RCA VioletRCA Violet
Connector A: RCA WhiteRCA White
Connector A: RCA YellowRCA Yellow
Connector A: RCA Female (+$2.80)RCA Female (+$2.80)
Connector A: RCA Right Angle (+$4.34)RCA Right Angle (+$4.34)
Connector A: XLR Female Mini (TA3FL) (+$8.46)XLR Female Mini (TA3FL) (+$8.46)
Connector A: XLR Female Mini (TA5FL) (+$12.78)XLR Female Mini (TA5FL) (+$12.78)
Connector A: XLR Female Mini (TA4FL) (+$14.20)XLR Female Mini (TA4FL) (+$14.20)
Connector A: XLR Female Mini (TA4FL) / Locking Ring (Amphenol) (+$15.60)XLR Female Mini (TA4FL) / Locking Ring (Amphenol) (+$15.60)
Connector A: XLR Male Mini (TA3ML) (+$10.14)XLR Male Mini (TA3ML) (+$10.14)
Connector A: XLR Male Mini (TA4ML) (+$12.63)XLR Male Mini (TA4ML) (+$12.63)
Connector A: XLR Male Mini (TA5ML) (+$13.14)XLR Male Mini (TA5ML) (+$13.14)
Connector A: Euro Block 3 Pin 3.81mm (+$3.54)Euro Block 3 Pin 3.81mm (+$3.54)
Connector A: Euro Block 3 Pin 5.00mm (+$3.54)Euro Block 3 Pin 5.00mm (+$3.54)
Connector A: Euro Block 3 Pin 3.5mm (+$5.39)Euro Block 3 Pin 3.5mm (+$5.39)
Connector A: Ferrule (-$0.31)Ferrule (-$0.31)
Connector A: Fork Terminals (-$0.06)Fork Terminals (-$0.06)
Connector A: EDAC E3F 3 Pin Female (+$0.64)EDAC E3F 3 Pin Female (+$0.64)
Connector A: EDAC E3M 3 Pin Male (+$0.64)EDAC E3M 3 Pin Male (+$0.64)
  Connector A
  Connector A
  Connector A
  Connector A
  Connector A
  Connector A
Label:
(+$3.00)
Length:
Length Additional:  -Added to Length, for over 100ft
Shrink Color Label:
  Shrink Color Label
Click image to enlarge
Shrink Color Label: NoNo
Shrink Color Label: Black (+$0.50)Black (+$0.50)
Shrink Color Label: Blue (+$0.50)Blue (+$0.50)
Shrink Color Label: Brown (+$0.50)Brown (+$0.50)
Shrink Color Label: Gray (+$0.50)Gray (+$0.50)
Shrink Color Label: Green (+$0.50)Green (+$0.50)
Shrink Color Label: Orange (+$0.50)Orange (+$0.50)
Shrink Color Label: Red (+$0.50)Red (+$0.50)
Shrink Color Label: Violet (+$0.50)Violet (+$0.50)
Shrink Color Label: White (+$0.50)White (+$0.50)
Shrink Color Label: Yellow (+$0.50)Yellow (+$0.50)
  Shrink Color Label
Special Instructions:  -Other wiring requests and changes; Fees may apply
Quantity:
Qty Discount at: 30
